Image Sensor
|
5MP Progressive scan Cmos Sensor (1/2.8”) |
|---|
|
CPU
|
Dual-Core ARM Cortex-A7@900 MHz |
|---|
|
Lens
|
3.6 mm Fixed Lens @F1.0 |
|---|
|
Resolution
|
2592*1944 (5MP) |
|---|
|
Available IR Range
|
30~40 M Smart IR SMD Technology (2pcs IR SMD)
30 m Warm Light Technology (2 pcs Warm Light)
Smart light Technology |
|---|
|
D/N Filter
|
IR cut filter with auto switch |
|---|
|
Min Illumination
|
Color: 0.003 Lux(AGC on) – B/W: 0.0 Lux(IR on) |
|---|
|
Angle of View
|
H-FOV: 91°, V-FOV: 50°, D-FOV: 106° |
|---|
|
Night Light
|
Dual Light Technology |
|---|
|
Picture Function
|
120dB WDR/DWDR, 2D/3D DNR, BLC, HLC, ROI, Defog, Rotate |
|---|
|
Shutter Speed
|
Manual (1/3 ~ 1/10.000), Auto |
|---|
|
Image Parameter Control
|
Off, On, Timing (Adjust 0 ~ 255) |
|---|
|
D/N Control
|
Timing, Auto , Color on, Color off |
|---|
|
S/N
|
> 52dB |
|---|
|
Image Parameter
|
Saturation, Brightness, Contrast, Sharpness, Hue |
|---|
|
Video Compression
|
H.264+(Ultra H.264), H.265+ (Ultra H.265) |
|---|
|
Audio Compression
|
G.711A, G.711U |
|---|
|
Frame Rate(60Hz)
|
25fps@ 5MP (2592*1944), 30fps@ 3MP, 30fps@ 2MP |
|---|
|
Transmission Stream
|
Triple Stream (Video Bit Rate:11 Kbps~10 Mbps) |
|---|
|
Protocols
|
TCP/IP(V4, V6), ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, IGMP, UPnP, SMTP, UPnP-TM, P2P, Bonjour, SNMP (V1, V2, V3), UDP, NAT, Multicast, RTMP |
|---|
|
Compatibility
|
Onvif Ver2.6, Profile S, G, T, CGI, SDK, API |
|---|
|
Streaming Method
|
Unicast, Multicast |
|---|
|
Web Viewer
|
IE, Edge, Firefox, Chrome |
|---|
|
Smart Device
|
IOS, Android Phone & Tablet |
|---|
|
Recording
|
FTP, NVR, CMS, VMS, SD Card, ANR |
|---|
|
Record Type
|
Manual, Motion Detection, Smart Detection, Schedule |
|---|
|
Alarm Triggers
|
All Intelligent Function |
|---|
|
Event Action
|
Email, PTZ, Snapshot, Recording, Buzzer, Pop up, Show Message, Smart Light |
|---|
|
Event
|
Motion Detection, Video Shelter |
|---|
|
Intelligent Function
|
5 Smart Function
Line Crossing, Area Intrusion, Region Entrance, Region Exiting, Fast Moving |
|---|
|
Network
|
1 RJ45 (10M / 100M) Ethernet Port |
|---|
|
Audio
|
Internal Mic |
|---|
|
Alarm
|
N/A |
|---|
|
CVBS
|
N/A |
|---|
|
Power
|
PoE LAN, DC In |
|---|
|
Reset Button
|
Yes (Optional) |
|---|
|
Memory Slot
|
Yes – Micro SD/SDHC/SDXC Slot (256 Gb Max) (ANR Support) |
|---|
|
IP Rating
|
IP67, 2KV Surge Protection |
|---|
|
Power Supply
|
DC12V ± 10% |
|---|
|
POE Supply
|
IEEE802.3af – Max 7 Watt |
|---|
|
Web Language
|
English, Persian |
|---|
|
Dimension
|
103*84 mm |
|---|
|
Weight
|
450 g |
|---|
|
Operation Humidity
|
Humidity 95% or less (non-condensing) |
|---|
|
Operation Temp
|
-30°C ~ +60°C |
|---|
|
Product Guarantee
|
2 Years Silver Guarantee |
|---|
|
MTBF
|
100K hrs min. MIL-HDBK-217F (25°) |
|---|
|
Certificates
|
EN, CN, FCC, CFR |
|---|
