Image Sensor
|
6MP (Sony-Japan) Progressive scan Cmos Sensor (1/2.8”) |
|---|
|
CPU
|
Dual-Core ARM Cortex-A7@900MHz |
|---|
|
Lens
|
3.6 mm Fixed Lens @F1.6, (2.8 mm Optional) |
|---|
|
Resolution
|
3200*1800 (6MP) |
|---|
|
Available Warm Light Range
|
Smart Light Technology30 m Warm Light Technology (2 pcs Warm Light) 40~50 m Smart IR SMD Technology (1pcs IR SMD) |
|---|
|
D/N Filter
|
IR cut filter with auto switch |
|---|
|
Min Illumination
|
Color: 0.001 lux(AGC on) – 0.0 Lux(IR on) |
|---|
|
Angle of View
|
H-FOV: 89°-(108°), V-FOV: 46°-(58°), D-FOV: 106°-(128°) |
|---|
|
Night Vision
|
Dual Light Technology |
|---|
|
Picture Function
|
120dB WDR/DWDR, 2D/3D DNR, BLC, HLC, ROI, Defog |
|---|
|
Shutter Speed
|
Manual (1/3 ~ 1/100.000), Auto |
|---|
|
Image Parameter Control
|
Off, On, Timing (Adjust 0 ~ 255) |
|---|
|
D/N Control
|
Timing, Auto, Color on, Color off |
|---|
|
Image Parameter
|
Saturation, Brightness, Contrast, Sharpness, Hue |
|---|
|
S/N
|
> 56dB |
|---|
|
Video Compression
|
H.264+(Ultra H.264), H.265+ (Ultra H.265), MJPEG |
|---|
|
Audio Compression
|
G.711A, G.711U |
|---|
|
Frame Rate (60Hz)
|
30fps@ 6MP(3200*1800), 30fps@ 4MP, 30fps@ 2MP |
|---|
|
Transmission Stream
|
Triple Stream (Video Bit Rate:11 Kbps~16Mbps) |
|---|
|
Protocols
|
TCP/IP(V4, V6), ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, IGMP, UPnP, SMTP, UPnP-TM, P2P, Bonjour, SNMP (V1, V2, V3), UDP, NAT, Multicast, RTMP |
|---|
|
Compatibility
|
Onvif Ver2.6, Profile S, G, T, CGI, SDK, AP |
|---|
|
Streaming Method
|
Unicast, Multicast |
|---|
|
Web Viewer
|
IE, Edge, Firefox, Chrome |
|---|
|
Smart Device
|
IOS, Android Phone & Tablet |
|---|
|
Recording
|
FTP, NVR, CMS, VMS, NAS, SD Card, ANR |
|---|
|
Record Type
|
Manual, Motion Detection, Smart Detection, Schedule |
|---|
|
Alarm Triggers
|
All Intelligent Function |
|---|
|
Event Action
|
Email, PTZ, Snapshot, Recording, Buzzer, Pop up, Show Message, Smart Light |
|---|
|
Event
|
Motion Detection, Video Shelter |
|---|
|
Intelligent Function
|
Line Crossing, Area Intrusion, Region Entrance, Region Exiting, Fast Moving, Loitering Detection, Blurred Detection, Scene Change Detection, Audio exception Detection, Face Detection |
|---|
|
Network
|
1 RJ45 (10M / 100M) Ethernet Port |
|---|
|
Audio
|
Internal Mic, Audio Out, Audio in |
|---|
|
Alarm
|
Alarm Out, Alarm In |
|---|
|
CVBS
|
N/A |
|---|
|
Power
|
PoE LAN, DC In |
|---|
|
reset Button
|
Yes (Optional) |
|---|
|
Memory Slot
|
Yes – Micro SD/SDHC/SDXC Slot (256 Gb Max) (ANR Support) |
|---|
|
Product Guarantee
|
5 Years Gold Guarantee |
|---|
|
MTBF
|
100Khrs min. MIL-HDBK-217F (25°) |
|---|
|
Certificate
|
EN, CN, FCC, CFR |
|---|
