| Image Sensor |
5MP Progressive scan Cmos Sensor (1/2.8”) |
|---|---|
| CPU |
Dual-Core ARM Cortex-A7@900MHz |
| Lens |
2.8 mm Fixed Lens @F1.6 |
| Resolution |
2592*1944 (5MP) |
| Available IR Range |
15~25 m Smart IR SMD Technology |
| D/N Filter |
IR cut filter with auto switch |
| Min Illumination |
Color: 0.01 lux(AGC on) – B/W: 0.0 Lux(IR on) |
| Angel of View |
H-FOV: 96°, V-FOV: 79°, D-FOV: 119° |
| Night Vision |
Color /IR |
| Picture Function |
120 db WDR/DWDR, 2D/3D DNR, BLC, HLC, ROI, Defog, Rotate |
| Shutter Speed |
Manual (1/3 ~ 1/10.000), Auto |
| Image Parameter Control |
Off, On, Timing (Adjust 0 ~ 255) |
| D/N Control |
Timing, Auto , Color on, Color off |
| S/N |
> 52dB |
| Image Parameter |
Saturation, Brightness, Contrast, Sharpness, Hue |
| Video Compression |
H.264+(Ultra H.264), H.265+ (Ultra H.265) |
| Audio Compression |
G.711A, G.711U |
| Frame Rate(60Hz) |
25fps@ 5MP (2592*1944), 30fps@ 3MP, 30fps@ 2MP |
| Transmission Stream |
Triple Stream (Video Bit Rate:11 Kbps~8 Mbps) |
| Protocols |
TCP/IP(V4, V6), ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, IGMP, UPnP, SMTP, UPnP-TM, P2P, Bonjour, SNMP (V1, V2, V3), UDP, NAT, Multicast, RTMP |
| Compatibility |
Onvif Ver2.6, Profile S, G, T, CGI, SDK, API |
| Streaming Method |
Unicast, Multicast |
| Web Viewer |
IE, Edge, Firefox, Chrome |
| Smartphone |
IOS, Android Phone & Tablet |
| Recording |
FTP, NVR, CMS, NAS, SD Card, ANR |
| Record Type |
Manual, Motion Detection, Smart Detection, Schedule |
| Alarm Triggers |
All Intelligent Function |
| Event Action |
Email, PTZ, Snapshot, Recording, Buzzer, Pop up, Show Message |
| Event |
Smart Motion Detection, Video Shelter |
| Intelligent Function |
5 Smart Function |
| Network |
1 RJ45 (10M / 100M) Ethernet Port |
| Audio |
Internal Mic, Audio Out, Audio In |
| Alarm |
N/A |
| CVBS |
N/A |
| Power |
PoE LAN, DC In |
| Reset Button |
Yes (Optional) |
| Memory Slot |
Yes – Micro SD/SDHC/SDXC Slot (256 Gb Max) (ANR Support) |
| IP Rating |
IP67, IK10, 2KV Surge Protection |
| Power Supply |
DC12V ± 10% |
| POE Supply |
IEEE802.3af – Max 6 Watt |
| Web Language |
English, Persian |
| Dimension |
105*52mm |
| Weight |
380g |
| Operation Humidity |
Humidity 95% or less (non-condensing) |
| Operation Temp |
-30°C ~ +60°C |
| Product Guarantee |
2 Years Silver Guarantee |
| MTBF |
100K hrs min. MIL-HDBK-217F (25°) |
| Certificate |
EN, CN, FCC, CFR |
