CPU
|
Dual-Core ARM Cortex-A7@900 MHz |
|---|
|
Lens
|
2.8 mm Fixed Lens @F1.6 |
|---|
|
Resolution
|
3840*2160 (8MP) |
|---|
|
Available IR Range
|
30~40 m Smart IR SMD Technology
Smart White light Technology |
|---|
|
D/N Filter
|
IR cut filter with auto switch |
|---|
|
Min Illumination
|
Color: 0.006 Lux(AGC on) – B/W: 0.0 Lux(IR on) |
|---|
|
Angle of View
|
H-FOV: 114°, V-FOV: 58°, D-FOV: 120° |
|---|
|
Night Light
|
Color /IR |
|---|
|
Picture Function
|
120dB WDR/DWDR, 2D/3D DNR, BLC, HLC, ROI, Defog, Rotate |
|---|
|
Shutter Speed
|
Manual (1/3 ~ 1/10.000), Auto |
|---|
|
Image Parameter Control
|
Off, On, Timing (Adjust 0 ~ 255) |
|---|
|
D/N Control
|
Timing, Auto , Color on, Color off |
|---|
|
S/N
|
> 52dB |
|---|
|
Image Parameter
|
Saturation, Brightness, Contrast, Sharpness, Hue |
|---|
|
Video Compression
|
H.264+(Ultra H.264), H.265+ (Ultra H.265) |
|---|
|
Audio Compression
|
G.711A, G.711U |
|---|
|
Frame Rate(60Hz)
|
20fps@ 8MP (3840*2160), 20fps@ 6MP, 30fps@ 4MP, 30fps@ 2MP |
|---|
|
Transmission Stream
|
Triple Stream (Video Bit Rate:11 Kbps~8 Mbps) |
|---|
|
Protocols
|
TCP/IP(V4, V6), ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, IGMP, UPnP, SMTP, UPnP-TM, P2P, Bonjour, SNMP (V1, V2, V3), UDP, NAT, Multicast,RTMP |
|---|
|
Compatibility
|
Onvif Ver2.6, Profile S, G, T, CGI, SDK, API |
|---|
|
Streaming Method
|
Unicast, Multicast |
|---|
|
Web Viewer
|
IE, Edge, Firefox, Chrome |
|---|
|
Smart Device
|
IOS, Android Phone & Tablet |
|---|
|
Recording
|
FTP, NVR, CMS, SD Card, ANR |
|---|
|
Record Type
|
Manual, Motion Detection, Smart Detection, Schedule |
|---|
|
Alarm Triggers
|
All Intelligent Function |
|---|
|
Event Action
|
Email, PTZ, Snapshot, Recording, Buzzer, Pop up, Show Message, Smart Light |
|---|
|
Event
|
Smart Motion Detection, Video Shelter |
|---|
|
Intelligent Function
|
14 Smart Function
Line crossing detection, Area intrusion, Unattended Object, Object Missing Region Entrance, Region Exiting, Fast Moving, Loitering Detection, People Gathering Detection, Parking Detection, Blurred Detection, Scene Change Detection, Audio exception Detection, Crossing Line Statistics |
|---|
|
Network
|
1 RJ45 (10M / 100M) Ethernet Port |
|---|
|
Audio
|
Internal Mic |
|---|
|
Alarm
|
N/A |
|---|
|
CVBS
|
N/A |
|---|
|
Power
|
PoE LAN, DC In |
|---|
|
Reset Button
|
Yes (Optional) |
|---|
|
Memory Slot
|
Yes – Micro SD/SDHC/SDXC Slot (256 Gb Max) (ANR Support) |
|---|
|
IP Rating
|
IP67, IK10, 6KV Surge Protection |
|---|
|
Power Supply
|
DC12V ± 10% |
|---|
|
POE Supply
|
IEEE802.3af – Max 7 Watt |
|---|
|
Web Language
|
English, Persian |
|---|
|
Dimension
|
112*87.5 mm |
|---|
|
Weight
|
450 g |
|---|
|
Operation Humidity
|
Humidity 95% or less (non-condensing) |
|---|
|
Operation Temp
|
-30°C ~ +60°C |
|---|
|
Product Guarantee
|
2 Years Silver Guarantee |
|---|
|
MTBF
|
100K hrs min. MIL-HDBK-217F (25°) |
|---|
|
Certificates
|
EN, CN, FCC, CFR |
|---|
