| Image Sensor |
2MP Super Starligh (Sony-Japan) Progressive scan Cmos Sensor (1/2”) |
|---|---|
| CPU |
Dual-Core ARM Cortex-A7@900 MHz |
| Lens |
38X Optical Lens (6.8~260 mm) F-Stop F1.5~F4.8) |
| Resolution |
1920*1080 (2MP) |
| Available IR Range |
600 m Smart Optical Laser IR Technology |
| D/N Filter |
IR Cut Filter Switch (ICR) |
| Min Illumination |
Color: 0.001 Lux(AGC on) – B/W: 0.0 Lux(IR on) |
| PTZ |
Pan Range: 360° Endless – Pan Speed: 0.1°~240°/S |
| Night Vision |
Super Starlight Technology |
| Picture Function |
120dB WDR,DWDR, BLC, HLC, Defog, ROI |
| Image Stabilization |
Yes(DIS) |
| Optical Defog |
Yes |
| Digital Zoom |
16X |
| Shutter Speed |
Manual (1/3 ~ 1/100.000), Auto |
| Image Control |
Off, On, Timing (Adjust 0 ~ 255) |
| D/N Control |
Timing, Auto , Color on, Color off |
| Image Parameter |
Saturation, Brightness, Contrast, Sharpness, Hue |
| Video Compression |
H.264+(Ultra H.264), H.265+(Ultra H.265) |
| Audio Compression |
G.711A, G.711U |
| Frame Rate |
30fps@(1920×1080) |
| Transmission Stream |
Triple Stream (Code Rate: 128Kbps-16mbps) |
| Protocols |
HTTPs, HTTP, TCP/IP V4-V6, ICMP, RTSP, UDP, NTP, DHCP, |
| Compatibility |
Onvif Ver2.6, Profile S, CGI, SDK, API |
| Streaming Method |
Unicast, Multicast |
| Web Viewer |
Internet Explorer |
| Recording |
FTP, NVR, CMS, VMS, SD Card |
| Record Type |
Manual, Motion Detection, Smart Detection, Schedule |
| Alarm Triggers |
N/A |
| Event Action |
Email, PTZ, Snapshot, Recording, Alarm Out |
| Event |
Motion Detection, Video Shelter |
| Intelligent Function |
N/A |
| Network |
1 RJ45 (10M / 100M) Ethernet Port |
| Audio |
Audio Out, Audio In |
| Alarm |
Alarm Out, Alarm In |
| CVBS |
N/A |
| Power |
PoE LAN, DC/AC In |
| Reset Button |
N/A |
| Memory Slot |
Yes – Micro SD/SDHC/SDXC Slot (128 Gb Max) |
| IP Rating |
IP67 , IK10, 3KV Surge Protection |
| Cover Lens |
Nano Glass |
| Wiper |
Yes |
| Power Supply |
AC24 V ± 25% (4A Max) |
| POE Supply |
IEEE802.3at.af-Max 30 Watt |
| Web Language |
English, Persian |
| Dimension |
380*235 mm |
| Weight |
8 kg |
| Case Size |
8 |
| Operation Humidity |
Max Up to 95%RH(Non Condensing) |
| Operation Temp |
-40°C ~ +70°C |
| Product Guarantee |
2 Years Silver Guarantee |
| MTBF |
100K hrs min. MIL-HDBK-217F (25°) |
